GN 782

Ball Joints

Steel / Stainless Steel

GN 782

Ball Joints
Axial ball joints

GN 782-KI-NI

Ball Joints
Type KI, Stainless Steel

GN 782-KI-ST

Ball Joints
Type KI, Steel

GN 782-KS-NI

Ball Joints
Type KS, Stainless Steel

GN 782-KS-ST

Ball Joints
Type KS, Steel

GN 782

Ball Joints
Axial ball joints

Types

  • Type KS: Ball with male thread
  • Type KI: Ball with female thread

Identification No.

  • No. 1: Mounting socket with female thread
  • No. 2: Mounting socket with male thread

Steel

zinc plated, blue passivated

Brake piece

Technopolymer (Polyamide PA)

The clamping nut of the axial ball joints GN 782 can be set to give a required thrust on the Belleville spring washers in order to increase the resistance to the ball movement.

At the same time the Belleville spring washers act as safety washers for the screws.

Once the max. thrust to the Belleville spring washers is reached the ball arm is firmly immobilised in position over the clamping nut and screw.
